Innovative solutions
Generator sets, ship power, construction machinery, fixed power, vehicle machine and other "diversified low-carbon clean power electronic control platform"

Natural gas generator set type spectrum

Product Description

        Gas generator set is a new type of generator set developed to meet the requirements of global environmental protection

and the new market environment. There are two main types of natural gas generator sets, one is a combined cycle gas turbine and

the other is a gas internal combustion engine. Gas turbines have relatively high power, mainly used in large and medium-sized

power plants, while gas internal combustion engines have relatively low power, mainly used in small distributed power plants.

It is a new type of green and environmentally friendly power that replaces fuel and coal-fired units.


         The power coverage range of gas generator units is 50-4300KW, and parallel units are recommended for units above 500KW;

 Including standard open type units, standard silent type units, rainproof shed type units, and container silent type units.


Product specifications


Natural gas generator unit/cogeneration unit

ID

Model

Power

Power factor

Voltage

Frequency

Speed

kVA

kW

1

XKN25

25

20

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

2

XKN38

37.5

30

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

3

XKN63

62.5

50

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

4

XKN125

125

100

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

5

XKN188

187.5

150

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

6

XKN250

250

200

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

7

XKN313

312.5

250

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

8

XKN375

375

300

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

9

XKN438

437.5

350

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

10

XKN500

500

400

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

11

XKN525

525

420

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

12

XKN625

625

500

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

13

XKN650

650

520

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

14

XKN750

750

600

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

15

XKN1000

1000

800

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

16

XKN1250

1250

1000

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

17

XKN1500

1500

1200

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

18

XKN1875

1875

1500

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

19

XKN1950

1950

1560

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

20

XKN2500

2500

2000

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

21

XKN5625

5625

4500

Φ= 0.8(滞后)

400/230V

50Hz

1500rpm

Note:

1. The engine used for the unit can be from brands such as Cummins, Weichai, Yuchai, Kubota, Yunnei, etc;

2. Generators for the unit can be selected from brands such as Stanford, Faraday, Lilisenma, and Marathon.

3. The above parameters may be modified at any time. For the latest technical parameters of related products, please consult our sales personnel!
